型號

規格

筒體轉速

裝球重量

給料粒度

出料粒度

產量

電動機Motor

外形尺寸

重量

Model

Standards

Barrel rotating

speed(r/min)

Weight with

balls(t)

Max Feeding

size(mm)

Output Size

(mm)

Capacity

(t/h)

型號

Model

功率

Power (kW)

Dimension

(LxWxH) (mm)

Weight

(kg)

GMG(Y)0918

Φ900x1800

41.6

1.6

15

0.074-0.3

0.58-1.3

Y200L-1

18.5

3510x3668x1754

7000

GMG(Y)0932

Φ900x3200

41.6

3

15

0.074-0.3

0.9-2.3

Y225M-6

30

3910x3668x1754

7260

GMG(Y)1212

Φ1200x1200

35.2

2.4

20

0.074-0.6

0.4-2.19

Y250S-8

18.5

5320x2850x2540

9028

GMG(Y)1224

Φ1200x2400

35.2

4.8

20

0.075-0.6

0.8-7.5

Y280S-8

37

3920x2850x2540

11450

GMG(Y)1250

Φ1200x5000

31

7.4

20

0.074-0.6

2.3-11.7

JR115-8

60

6520x2850x2540

15000

GMG(Y)1515

Φ1500x1500

31

5.5

30

0.074-0.6

1.1-3.7

Y280M-8

45

5033x2828x2490

14299

GMG(Y)1530

Φ1500x3000

31

10

30

0.074-0.6

3.3-8.8

JR117-8

80

7465x2938x2490

17700

GMG(Y)1536

Φ1500x3600

31

10

30

0.074-0.6

3.5-11

JR125-8

95

8190x2938x2490

19560

GMG(Y)1545

Φ1500x4500

27.6

12

30

0.074-0.6

3.0-16.5

JR126-8

110

7924x3178x2490

21080

GMG(Y)1557

Φ1500x5700

27.6

16

30

0.074-0.6

3.6-25

JR127-8

130

10024x3178x2490

23676

GMG(Y)1826

Φ1830x2600

25.2

11

25

0.074-0.6

2-15

JR126-8

110

7830x3743x3394

30533

GMG(Y)1830

Φ1830x3000

25.2

12.5

25

0.074-0.6

2.3-18

JR128-8

155

8505x3911x3394

32520

GMG(Y)1836

Φ1830x3600

25.2

15

25

0.074-0.6

2.5-21

JR128-8

155

9105x3911x3394

34125

GMG(Y)1856

Φ1830x5600

25.2

21

25

0.074-0.6

4-30

JR138-8

245

11105x3911x3394

43463

GMG(Y)2122

Φ2100x2200

23.8

15.7

25

0.074-0.6

3-24

JR128-8

155

7700x4700x4400

37304

GMG(Y)2130

Φ2100x3000

23.8

20

25

0.074-0.6

4-30

JR136-8

180

8500x4700x4400

41900

GMG(Y)2137

Φ2100x3750

23.8

25

25

0.074-0.6

5-37.5

JR137-8

210

9250x4700x4400

45355

GMG(Y)2140

Φ2100x4000

23.8

25

25

0.074-0.6

5.2-40

JR138-8

245

9713x4023x3394

47709

GMG(Y)2145

Φ2100x4500

23.8

26

25

0.074-0.6

5.6-42

JR138-8

245

10213x4023x3394

48912

GMG(Y)2170

Φ2100x7000

23.8

39

25

0.074-0.6

8.7-65

JR158-8

380

12797x4287x3394

62600

GMG(Y)2275

Φ2200x7500

21

42.5

25

0.074-0.6

8.4-63

JR158-8/JR1510-8

380/475

13745x5549x3794

73819/72523

GMG(Y)2430

Φ2400x3000

23

22.2

25

0.074-0.6

5.5-69

JR1410-8

280

9160x5464x3966

62104

GMG(Y)2436

Φ2400x3600

23

26.6

25

0.074-0.6

6.5-82

JR1410-8

280

9760x5464x3966

66517

GMG(Y)2445

Φ2400x4500

23

33.3

25

0.074-0.6

8.1-100

JR1510-8

320

10660x5464x3966

73420

GMG(Y)2475

Φ2400x7500

23

54

25

0.074-0.6

12-165

JR1512-8

570

14180x5620x3966

96760

GMG(Y)2736

Φ2700x3600

21.7

34

25

0.074-0.6

15-118

JR1510-8

475

10740x5939x4510

89015

GMG(Y)2756

Φ2700x5600

21.7

43

25

0.074-0.5

15-141

TDMK500-32/2150

500

13277x5800x4675

107725

GMG(Y)3236

Φ3200x3600

18.5

51

25

0.074-0.5

86-100

TDMK630-36/2600

630

14254x6731x5201

33541

GMG(Y)3245

Φ3200x4500

18.5

61

25

0.074-0.5

86-100

TDMK800-36/2600

800

15354x6731x5201

141212

GMG(Y)3256

Φ3200x5600

18.5

79

25

0.074-0.5

95-120

TDMK1000-36

1000

16456x6731x5201

152680

GMG(Y)3645

Φ3600x4500

17.3

88

25

0.074-0.5

110-140

TDMK1250-40

1250

15000x7200x6300

161230

GMG(Y)3660

Φ3600x6000

17.3

111

25

0.074-0.5

160-220

TDMK1600-40

1600

17000x7700x6300

185662
